(1) Advanced design

Designed for exceptional performance, this tank comprise an inner container and an outer shell that carefully preserves a vacuum insulation inter-layer. It is equipped with a comprehensive suite of accessories, instrumentation, and systems meticulously designed to meet your operational requirements with precision.

Double-layer structure

At the core of our tank's innovation is an advanced thermal insulation technique that leverages porous particulate thermal insulation material and vacuum technology. This groundbreaking combination allows you to store LNG under the ideal conditions of low temperature and normal pressure. The result? An LNG storage solution that ensures the highest level of safety, quality, and efficiency, setting new standards in the industry.

(3) Process control advantages

The company has established a stable process control system in accordance with current national regulations, specifications, standards, etc. Through continuous transformation and upgrading of new technologies and process methods, the current manufacturing process level has reached a high level in the industry.

★★★ Product parameters ★★★
LO2/LN2/LAr Tank Type II
Capacity (CBM) 5-200
Orientation Vertical Double-layer Tank
Parameter name Inner container Shell
Working Pressure 1.6 -0.1
Design Pressure 1.64 -0.1
Medium LN2/LO2/LAr Perlite
Density (kg/m3) 808/1140/1374 120
Main Material S30408 Q245R
Filling Ratio/td> 0.95
Design service life 20 years
Design, Manufacturing and Inspection Standard GB, ASME
Detection method Non-destructive testing, helium leak test of interlayer

*The above product data is for reference only. Please refer to the actual product and product manual for specific information. Unless otherwise specified, all data interpretation rights involved in this website belong to CJSE.


It is widely used in LNG receiving station, storage station, vaporization station, and export station, etc.
